Railing Base Flange

Railing Base Flange
Railing Base Flange
Product Code : P-612
Product Description

RAILING BASE FLANGE

Ideal when a structural fixing is required for guard rail and balustrades. The holes are of sufficient diameter to insure proper fixing with either mechanical or chemical anchor. The two set screws in the vertical socket give greater side-load stability to the upright. It is recommended that the fixing holes in the flange should be in line with the applied load.

Prod. No.

612AA

612A

612B

612C

612D

Size (Inchs)

3/4

1

2

Pipe O. D (MM)

26.90

33.70

42.40

48.30

60.30

Dimension (A)

77.00

91.00

92.00

93.00

127.00

Dimension (B)

118.00

128.00

140.00

157.00

164.00

Dimension (C)

28.00

35.00

44.00

50.00

62.00

Dimension (D)

38.00

46.00

55.00

62.00

75.00

Wt. (Kgs.)

0.730

0.890

1.110

1.380

1.940
